Usage via GeoServer's REST API¶

The Backup and Restore REST API exposes a small set of resources, used asynchronously: you start a backup or restore with a POST, then poll the returned execution with a GET until it reaches a terminal state. The same engine, options and filters used by the user interface are available here, plus a few REST-only options (see all options).

Warning

Backup and Restore is a GeoServer community module. It is experimental and comes with weaker guarantees than official extensions: APIs and behaviour may change between releases. Always run a BK_DRY_RUN=true restore first, and keep a known-good archive before restoring into a live instance.

Backup and Restore saves or reloads the GeoServer catalog and configuration (workspaces, stores, layers, styles, layer groups, GeoWebCache configuration, services, and global and security settings). It does not copy the underlying data — only the configuration that references it.

Resources¶

The REST base path is /rest/br. Both representations (.json and .xml) are supported; the examples below use JSON.

Resource	Method	Description
`/rest/br/backup`	`GET`	List all backup executions known to the running instance.
`/rest/br/backup`	`POST`	Start a new backup. Body is a JSON/XML document with the backup configuration (see below). Returns `201 Created`.
`/rest/br/backup/{id}.{json\\|xml}`	`GET`	Status of backup execution `{id}`, including per-step progress.
`/rest/br/backup/{id}.zip`	`GET`	Download the generated archive for execution `{id}`.
`/rest/br/backup/{id}`	`DELETE`	Cancel backup execution `{id}`. Add `?force=true` to escalate a wedged job (see Cancel or abort a job).
`/rest/br/restore`	`GET`	List all restore executions known to the running instance.
`/rest/br/restore`	`POST`	Start a new restore from a server-side archive. Body is a JSON/XML document with the restore configuration (see below). Returns `201 Created`.
`/rest/br/restore/{id}.{json\\|xml}`	`GET`	Status of restore execution `{id}`, including per-step progress.
`/rest/br/restore/{id}`	`DELETE`	Cancel restore execution `{id}`. Add `?force=true` to escalate a wedged job.

Note

The execution list is held in memory and is reset when GeoServer restarts. Download archives and note any execution detail you need before restarting the container.

Request body¶

A backup or restore is described by a single JSON object whose root key is backup or restore:

{
  "backup": {
    "archiveFile": "/var/backups/geoserver/backup1.zip",
    "overwrite": true,
    "options": {
      "option": ["BK_SKIP_SECURITY=false", "BK_PARAM_PASSWORDS=true"]
    },
    "wsFilter": "name IN ('topp','sf')"
  }
}

Field	Applies to	Meaning
`archiveFile`	both	Absolute path, on the server, of the `.zip` archive to write (backup) or read (restore). See the note on server-side paths below.
`overwrite`	backup	When `true`, replace an existing archive at `archiveFile`.
`options`	both	Object with an `option` array of `BK_KEY=value` strings. See all options.
`wsFilter` / `siFilter` / `liFilter`	both	Optional ECQL strings scoping the job to specific workspaces / stores / layers. See Filtered backup.

Note

The restore reads the archive from a server-side path: archiveFile must point to a .zip that the GeoServer process can read on its own file system. There is no client-side or multipart upload — copy the archive to a location GeoServer can reach, then reference its absolute path. (To move an archive between machines, download it with the .zip endpoint and place it on the target server.)

Examples¶

The examples use the command-line tool cURL against a GeoServer running at http://localhost:8080/geoserver, authenticating as the default admin user. Adjust the base URL, credentials and archive paths for your environment.

Start a full backup¶

Write the configuration to a file:

backup_post.json:

{
  "backup": {
    "archiveFile": "/var/backups/geoserver/backup1.zip",
    "overwrite": true,
    "options": {}
  }
}

With no options specified, the defaults apply (see all options). Post it:

curl -u admin:geoserver -H "Content-Type: application/json" \
  -X POST -d @backup_post.json \
  "http://localhost:8080/geoserver/rest/br/backup"

GeoServer answers 201 Created and returns the new execution. Note its id (here, 0) — you will use it to poll status and download the archive:

{
  "backup": {
    "execution": {
      "id": 0,
      "status": "STARTED",
      "progress": "1/8",
      "archiveFile": "/var/backups/geoserver/backup1.zip",
      "overwrite": true,
      "options": {
        "option": ["OVERWRITE=true"]
      }
    }
  }
}

Poll the status of an execution¶

Request the execution by id, adding the .json (or .xml) suffix:

curl -u admin:geoserver \
  "http://localhost:8080/geoserver/rest/br/backup/0.json"

The response reports the overall status and progress plus the list of steps, each with its own status, exit code and timings. A completed backup looks like:

{
  "backup": {
    "execution": {
      "id": 0,
      "status": "COMPLETED",
      "progress": "8/8",
      "startTime": "2026-06-06T10:21:14.802",
      "endTime": "2026-06-06T10:21:25.356",
      "exitStatus": {
        "exitCode": "COMPLETED",
        "exitDescription": ""
      },
      "stepExecutions": {
        "step": [
          {
            "name": "backupWorkspacesAndLayers",
            "status": "COMPLETED",
            "exitStatus": { "exitCode": "COMPLETED", "exitDescription": "" },
            "readCount": 12,
            "writeCount": 12,
            "failureExceptions": ""
          }
        ]
      },
      "archiveFile": "/var/backups/geoserver/backup1.zip"
    }
  }
}

The status is one of STARTING, STARTED, STOPPING, STOPPED, COMPLETED, FAILED or ABANDONED. Keep polling while it is STARTING or STARTED. The failureExceptions of a failed step carries the message chain and stack trace for troubleshooting.

Download the archive¶

Once the backup is COMPLETED, download the generated .zip by requesting the same resource with a .zip suffix:

curl -u admin:geoserver \
  "http://localhost:8080/geoserver/rest/br/backup/0.zip" -o backup.zip

Start a restore¶

Restore from a .zip already present on the server's file system. Write the configuration:

restore_post.json:

{
  "restore": {
    "archiveFile": "/var/backups/geoserver/backup1.zip",
    "options": {}
  }
}

Post it:

curl -u admin:geoserver -H "Content-Type: application/json" \
  -X POST -d @restore_post.json \
  "http://localhost:8080/geoserver/rest/br/restore"

As with a backup, GeoServer returns 201 Created and an execution with an id; poll /rest/br/restore/{id}.json until it reaches a terminal state.

Warning

With the default options a restore is destructive: it purges pre-existing resources (BK_PURGE_RESOURCES=true) before restoring. Validate first with a dry run, and pass BK_PURGE_RESOURCES=false to merge into the current catalog without deleting. See all options.

Dry-run and fail-on-invalid restore¶

Validate an archive without changing anything: a dry run assembles the restore catalog and rolls back the data directory when it finishes. Combine it with BK_FAIL_ON_INVALID=true to make the validation pass fail the job on the first invalid object instead of only recording warnings:

{
  "restore": {
    "archiveFile": "/var/backups/geoserver/backup1.zip",
    "options": {
      "option": ["BK_DRY_RUN=true", "BK_FAIL_ON_INVALID=true"]
    }
  }
}

curl -u admin:geoserver -H "Content-Type: application/json" \
  -X POST -d @restore_dryrun.json \
  "http://localhost:8080/geoserver/rest/br/restore"

A failing dry run ends with status FAILED; inspect the failureExceptions on the offending step. See Transactional dry-run and fail-on-invalid.

Filtered backup¶

Scope a backup (or restore) to selected workspaces, stores or layers with the wsFilter, siFilter and liFilter ECQL strings. To back up only the topp and sf workspaces:

{
  "backup": {
    "archiveFile": "/var/backups/geoserver/subset.zip",
    "overwrite": true,
    "options": {},
    "wsFilter": "name IN ('topp','sf')"
  }
}

curl -u admin:geoserver -H "Content-Type: application/json" \
  -X POST -d @backup_filtered.json \
  "http://localhost:8080/geoserver/rest/br/backup"

Note

A workspace-filtered archive omits the global and security configuration, so it cannot be used to restore the workspaces it does not contain. To migrate or consolidate a full catalog, back up the whole catalog and restore the workspaces you need. See the filter reference.

Cross-instance security migration¶

By default a backup excludes security and a restore does not apply it (BK_SKIP_SECURITY=true on both). To carry users, groups and roles to another instance, include security in the backup and merge it on restore. Merge mode adds the archive's principals to the target's existing security services, keeping the target's own configuration, keystore and master password — so it works even when the two master passwords differ.

Back up with security included:

{
  "backup": {
    "archiveFile": "/var/backups/geoserver/with-security.zip",
    "overwrite": true,
    "options": {
      "option": ["BK_SKIP_SECURITY=false"]
    }
  }
}

Restore it into the target, merging security:

{
  "restore": {
    "archiveFile": "/var/backups/geoserver/with-security.zip",
    "options": {
      "option": ["BK_SKIP_SECURITY=false", "BK_MERGE_SECURITY=true"]
    }
  }
}

Note

New principals keep their archived (digest) passwords; reversible passwords must be reset on the target afterwards. To instead replace the target's whole security folder from an archive encrypted under a different master password, use the REST-only BK_SOURCE_MASTER_PASSWORD / BK_TARGET_MASTER_PASSWORD parameters described in all options.

Parameterized store passwords¶

To produce an archive whose store passwords are substitutable tokens instead of encrypted values — useful when the target uses different database credentials — back up with BK_PARAM_PASSWORDS=true:

{
  "backup": {
    "archiveFile": "/var/backups/geoserver/parameterized.zip",
    "overwrite": true,
    "options": {
      "option": ["BK_PARAM_PASSWORDS=true"]
    }
  }
}

Each store password is written as a token such as ${workspaceName:storeName.passwd.encryptedValue}. On restore, supply the replacements with BK_PASSWORD_TOKENS, a comma-separated list of token=value pairs:

{
  "restore": {
    "archiveFile": "/var/backups/geoserver/parameterized.zip",
    "options": {
      "option": [
        "BK_PASSWORD_TOKENS=${ws:store1.passwd.encryptedValue}=secret1,${ws:store2.passwd.encryptedValue}=secret2"
      ]
    }
  }
}

Tip

Pass the substituted passwords as transient parameters; never commit them to scripts or logs.

Cancel or abort a job¶

Cancel a running backup or restore by sending a DELETE with its id:

curl -u admin:geoserver -X DELETE \
  "http://localhost:8080/geoserver/rest/br/restore/0"

The job is asked to stop cooperatively at the next step boundary.

If a job has wedged and is holding the GeoServer configuration write-lock — blocking the rest of the UI and API — an administrator can escalate with ?force=true. This is a break-glass, last-resort action: it interrupts the stuck job and forcibly releases the configuration lock.

curl -u admin:geoserver -X DELETE \
  "http://localhost:8080/geoserver/rest/br/restore/0?force=true"

Warning

Use ?force=true only when a job is genuinely stuck and the configuration lock will not release on its own. Forcibly releasing the lock mid-write can leave the data directory in an inconsistent state — have a backup ready.
